DIN 43650-C Shielded Overmolded PUR Cable Assembly
Price dependent upon specification — inquire below
Product Description
This DIN 43650-C shielded overmolded PUR cable assembly includes a black connector with 4 contacts and 9.4 mm contact spacing. It is designed with 20 AWG / 0.5 mm² conductors, 250 VAC / 300 VDC voltage rating, and IP65 protection.
DIN 43650-C Shielded Overmolded PUR Cable Assembly
Price dependent upon specification — inquire below
Product Highlights
- 4 contacts with 9.4 mm spacing
- 3 poles + Earth conductor configuration
- Ground pin positioned at 6 o’clock
- 20 AWG / 0.5 mm² conductor size
- Rated voltage: 250 VAC / 300 VDC
- M3 x 0.5 central fixing screw, L = 22.5 mm
- IP65 rating
- Conductor ends stripped back 5 mm and tinned
- Available Lengths: 1 meter, 3.5 meters, 5 meters, 7.5 meters, 10 meters, and 20 meters
