Product Description
The P213 series by Paquin includes the capability to offer our customers application-specific custom magnetic hall effect linear sensor designs.
We can accommodate maximum measurable displacement up to 45 mm. The displacement distance is proportional to the size and type of magnet as well as to the distance between the magnet and sensor. Magnet material options include ferrite, neodymium, alnico and more.
Each sensor can be calibrated to ensure maximum repeatability of the measurement in relation to the influences of displacement and temperature within the system.
Please contact team Paquin to initiate your project.
P213 Linear Sensors with 4...20mA and PNP Open Collector Fault Output
Price dependent upon specification — inquire below
No data sheet available for this product — contact our team to learn more.
Product Highlights
- 10...30 VDC power supply
- Fault Output: open collector PNP, Imax 100mA, Vmax 30 V
- Response time from 10...90% FS @ 1ms
- Displacement resolution 0.2mm
- Magnet materials ferrite, neodymium alnico and more
